Related Products
- Manufacture: Vaughan
- Model: STV4S
- 3-Blade Impeller
- 4″ Discharge
- S/N: 150956
- Date: 05/2020
- RPM: 1170
- Motor Power: 7.5HP Motor Rpm 1170
- Head: 18 Ft
- Flow: 610 gpm
- 51″ Diameter
- 7-7/8″ Inside Opening
- Stainless Steel
- Manufacture: Jeffrey Rader
- Job No. PM10-6697
- Model: 45×45 ESW
- S/N: E-1225
- Manufacture: Hymac
- Model: PPSF27
- S/N: 631-150-25-6871
- Manufacture: Boldrocchi
- Model: 90/120
- Compressor 3,5hp, 2.6kw, 60Hz. 600v 1700 rpm
118″ (3.0M) TRIM BELOIT PAPER MACHINE 1000 FPM (PM #2)
118″ (3.0M) TRIM BELOIT PAPER MACHINE 1000 FPM (PM #2)
Product ID: PG-PM2
118″ (3.0M ) TRIM BELOIT FOURDRINIER PAPER MACHINE 1000 FPM (PM# 2)
Mec-Fab 130″ Slice Air Pad HeadBox MFG 1993 with (22) Automatic Profile Adjustments
Mec-Fab Cantilevered Fourdrinier Section MFG 1993
(10) Suction Boxes; Foils; Wire Tension System; Wire Showers and Trim Showers
LG Industries Suction Couch Roll 29.7″ Diameter
Dual Nip 3-Roll Combination Press Section
(28) Dryer Section 132″ Face x 48″ Diameter Rated 150 PSI
Beloit 2-Roll Vertical Size Press
Manchester 2-Roll Calendar High PLI stack with spare rolls
Measurex Model 2090 UltraTech Gauging System Scanner
Honeywell 4G High Speed Cameras
Sandar Industries Model TUSAI-E Turn-Up System
Manchester Horizontal Track Reel with primary and secondary arms
Associated Machine Design – Langston Speedmaster Slitter Rewinder 4000 FPM (Rebuilt 2002)
ALL Nash Vacuum pumps
Allen Bradley Controls
All Associated Spare rolls
Last ran 60-260 GSM
Complete Engineering and documentation available on site
Machine last ran March 2021
Product id: PG-PM2
Description: DESCRIPTION: 118" (3.0M ) TRIM BELOIT FOURDRINIER PAPER MACHINE 1000..Vaughan STV4S Electric Submersible Pump
Vaughan STV4S Electric Submersible Pump
Product ID: PTD14003
Product id: PTD14003
Description: Manufacture: Vaughan Model: STV4S 3-Blade Impeller 4" Discharge S/N: 150956..51″ Stainless Steel Voith Turbo Separator ATS500 Rotor
51″ Stainless Steel Voith Turbo Separator ATS500 Rotor
Product ID: PC12424
Product id: PC12424
Description: 51" Diameter 7-7/8" Inside Opening Stainless SteelRader 45×45 ESW Rotary Airlock Feeder
Rader 45×45 ESW Rotary Airlock Feeder
Product ID: PM12378
Product id: PM12378
Description: Manufacture: Jeffrey Rader Job No. PM10-6697 Model: 45x45 ESW S/N:..Hymac PPSF27 Pulp Plus Screw Feeder, Rebuilt By Andritz March, 2005
Hymac PPSF27 Pulp Plus Screw Feeder, Rebuilt By Andritz March, 2005
Product ID: PC13741
Product id: PC13741
Description: Manufacture: Hymac Model: PPSF27 S/N: 631-150-25-6871Boldrocchi 90/120 Centrifugal Pump New Storeroom Spare
Boldrocchi 90/120 Centrifugal Pump New Storeroom Spare
Product ID: PM13178
Product id: PM13178
Description: Manufacture: Boldrocchi Model: 90/120 Compressor 3,5hp, 2.6kw, 60Hz. 600v 1700..156″ (3.92M) TRIM FOURDRINIER PAPER MACHINE 2,200 FPM NEW ALLEN BRADLEY DRIVE SYSTEM IN 2008
156″ (3.92M) TRIM FOURDRINIER PAPER MACHINE 2,200 FPM NEW ALLEN BRADLEY DRIVE SYSTEM IN 2008
Product ID: PG-PM1
156″ (3.92M) TRIM FOURDRINIER PAPER MACHINE 2,200 FPM
MacFab S/S Air Pad HeadBox (2013) With Honeywell Model ProFlow II Position Automatic Profile
50 – 235 GSM, Dilution System installed New in 2013.
Cantilevered Fourdrinier S/S Table with (11) Suction Boxes
Suction Couch Roll 194″ Face
Dandy Roll
1st Press Hewitt Suction Press
2nd Press Plain Press Nip Roll- Blind Drilled
Dryer Section: (38)100 PSI Dryers 183.5″ Face x 60″ Diameter
Flooded Nip Size Press 182″
Manchester 2-Roll Calendar 174″ Face Rated 900 PLI
Honeywell Model 4000 Gauging System Scanner
Air Turn Up System
Voith Horizontal Track Reel 174″ Wide
Jagenberg Vari-Step 65 Two Drum Slitter Rewinder s/n 30-23922 Mfg 1987. Dual (2) 250 HP Main motors.
Complete Nash Vacuum Pump System
All Allen Bradley Drives and Controls Updated 2008 with new sectional drives Dual HZ 50/60
Nash Pumps (2) CL9002 and (1) CL6002 (1) 904 T
GE 700HP 460V #3 FAN PUMP
Last ran 50-250 GSM
All Spare Associated Rolls
Complete Engineering and documentation available at site
Product id: PG-PM1
Description: DESCRIPTION: 156" (3.92M) TRIM FOURDRINIER PAPER MACHINE 2,200 FPM MacFab..
