Related Products
- Manufacture: Valmet
- Type: Shaft Bearing System
- Manufacture: Hagglunds
- Model: MA 283N0400
- S/N: 51301167
- Manufacture: Fisher
- Model: 95H-52
- Manufacture: Hymac
- Model: PPSF27
- S/N: 631-150-25-6871
- Contact us for more information!
- Manufacture: Smith Meter Inc.
- Log No. R1428E10063
- Max Press: 285 PSI
- Model No. 210 V-A/V-F 120/60
- Part Number: HAXRG902160XXHRD0-Z000060
- Manufacture: ABB
156″ (3.92M) TRIM FOURDRINIER PAPER MACHINE 2,200 FPM NEW ALLEN BRADLEY DRIVE SYSTEM IN 2008
156″ (3.92M) TRIM FOURDRINIER PAPER MACHINE 2,200 FPM NEW ALLEN BRADLEY DRIVE SYSTEM IN 2008
Product ID: PG-PM1
156″ (3.92M) TRIM FOURDRINIER PAPER MACHINE 2,200 FPM
MacFab S/S Air Pad HeadBox (2013) With Honeywell Model ProFlow II Position Automatic Profile
50 – 235 GSM, Dilution System installed New in 2013.
Cantilevered Fourdrinier S/S Table with (11) Suction Boxes
Suction Couch Roll 194″ Face
Dandy Roll
1st Press Hewitt Suction Press
2nd Press Plain Press Nip Roll- Blind Drilled
Dryer Section: (38)100 PSI Dryers 183.5″ Face x 60″ Diameter
Flooded Nip Size Press 182″
Manchester 2-Roll Calendar 174″ Face Rated 900 PLI
Honeywell Model 4000 Gauging System Scanner
Air Turn Up System
Voith Horizontal Track Reel 174″ Wide
Jagenberg Vari-Step 65 Two Drum Slitter Rewinder s/n 30-23922 Mfg 1987. Dual (2) 250 HP Main motors.
Complete Nash Vacuum Pump System
All Allen Bradley Drives and Controls Updated 2008 with new sectional drives Dual HZ 50/60
Nash Pumps (2) CL9002 and (1) CL6002 (1) 904 T
GE 700HP 460V #3 FAN PUMP
Last ran 50-250 GSM
All Spare Associated Rolls
Complete Engineering and documentation available at site
Product id: PG-PM1
Description: DESCRIPTION: 156" (3.92M) TRIM FOURDRINIER PAPER MACHINE 2,200 FPM MacFab..Valmet Shaft Bearing Unit 161309ST0 New Storeroom Spare
Valmet Shaft Bearing Unit 161309ST0 New Storeroom Spare
Product ID: PM11105
Product id: PM11105
Description: Manufacture: Valmet Type: Shaft Bearing SystemHagglunds MA 283N0400 Drive, 17768 Cm3/r Displacement,283 Nm/Bar Torque, 350 bar Pressure, Rated Speed 38 R/min
Hagglunds MA 283N0400 Drive, 17768 Cm3/r Displacement,283 Nm/Bar Torque, 350 bar Pressure, Rated Speed 38 R/min
Product ID: PC13757
Product id: PC13757
Description: Manufacture: Hagglunds Model: MA 283N0400 S/N: 51301167Fisher 95H-52 Self Containing Pressure Regulator, New
Fisher 95H-52 Self Containing Pressure Regulator, New
Product ID: PT9451
Product id: PT9451
Description: Manufacture: Fisher Model: 95H-52Hymac PPSF27 Pulp Plus Screw Feeder, Rebuilt By Andritz March, 2005
Hymac PPSF27 Pulp Plus Screw Feeder, Rebuilt By Andritz March, 2005
Product ID: PC13741
Product id: PC13741
Description: Manufacture: Hymac Model: PPSF27 S/N: 631-150-25-6871Timken Bearing Assembly for Pulper 3696 New Storeroom Spare
Timken Bearing Assembly for Pulper 3696 New Storeroom Spare
Product ID: PM13096
Product id: PM13096
Description: Contact us for more information!6″ 150# Smith Meter
6″ 150# Smith Meter
Product ID: PT13793
Product id: PT13793
Description: Manufacture: Smith Meter Inc. Log No. R1428E10063 Max Press: 285..Back Pull Out for Turbo Fan ABB Flakt #1 and #2 ; Rebuilt Storeroom Spare
Back Pull Out for Turbo Fan ABB Flakt #1 and #2 ; Rebuilt Storeroom Spare
Product ID: PM12488
Product id: PM12488
Description: Part Number: HAXRG902160XXHRD0-Z000060 Manufacture: ABB
